Mini Rechargeable Control for Mobile and Compact Equipment
The HZBOY M4 mini industrial remote control combines four configurable buttons, a rechargeable transmitter and a compact housing for vehicle-mounted and space-limited equipment. It is easy to carry, comfortable to operate and supplied with a lanyard for convenient daily use.
Key Advantages
- Compact and portable: pocket-size transmitter with a lanyard for convenient carrying and operation.
- Type-C rechargeable: built-in 400 mAh battery provides approximately 40–50 hours of operating time, depending on use.
- Four configurable buttons: button symbols, output functions and control logic can be matched to the equipment.
- IP65 protection: sealed enclosure resists dust and water spray in normal industrial environments.
- Stable wireless control: typically 50–100 m, with approximately 100–150 m possible in suitable open conditions.
- Color options: orange, yellow, blue and black housings are available for product identification and OEM projects.
Technical Specifications
| Model | HZBOY M4 |
|---|---|
| Control layout | 4 configurable function buttons |
| Transmitter power | Type-C rechargeable, 400 mAh battery |
| Operating time | Approx. 40–50 hours, depending on use |
| Operating distance | Typically 50–100 m; up to approx. 100–150 m in suitable open conditions |
| Protection rating | IP65 |
| Receiver voltage | DC 12–24V or AC/DC 24–450V, depending on receiver version |
| Warranty | 1 year |
| Color options | Orange, yellow, blue and black |
Typical Applications
- Truck tail lifts and vehicle-mounted lifting equipment
- Tow-truck and recovery winches
- Small lifting platforms and hydraulic systems
- Industrial doors, pumps and compact machinery
Final compatibility depends on the receiver voltage, number of required functions and equipment control logic.
Wiring Diagram and Installation Support
The wiring diagram depends on the selected receiver voltage and output assignments. Send us the equipment wiring diagram, control-box photo or existing receiver label before installation. HZBOY can confirm terminal functions and the correct receiver version. The model-specific wiring diagram will be inserted here when the final drawing is available.
How to Confirm the Correct M4 Configuration
- Confirm the equipment control-circuit voltage.
- List the four required button functions.
- Specify which functions must be interlocked or may operate together.
- Share the application, destination country and estimated quantity.
OEM/ODM and Factory Support
HZBOY supports customized button labels, receiver output logic, voltage, frequency options, transmitter color, logo and packaging. Every transmitter and receiver set is paired and function-tested before shipment.
- 100% functional testing before shipment
- CE, FCC and ISO 9001 support for applicable products
- Replacement transmitter and pairing assistance
- OEM/ODM service for distributors, vehicle-equipment suppliers and manufacturers
Frequently Asked Questions
Can the M4 replace a wired pendant?
In many applications it can, provided the receiver voltage, relay outputs and control logic match the machine.
Can the button symbols and color be customized?
Yes. Button labels, output functions, housing color, logo and packaging can be customized according to the order requirements.
Is the receiver included?
The M4 can be supplied as a complete paired transmitter-and-receiver set. Please confirm the required receiver voltage and output logic before ordering.
Request a Configuration Check
Send the quantity, receiver voltage, four required functions, equipment type and destination country. For replacement projects, include clear photos of the existing controller, receiver label and wiring diagram.
